Industrial Enhanced Thermal Camera
UTi720B Heavy Duty Thermal Camera
- Product Item : UTi720B
- Category： UNI-T
- IR resolution (Pixels):256×192
- Display:2.8” TFT (320×240)
- Field of view(FOV): 56°(H) × 42°(V)
- Thermal sensitivity(NETD):≤50mK
While continuing the sturdy & durable advantages of the last generation product, the performance of UTi720B has significant improvement. Super resolution & T-Mix algorithm are added for better imaging effect. Support to real-time monitor the temperature changes trend via video recording function. Complete one-stop functionality operation through connecting mobile APP via Wi-Fi.
Features :
Specifications
Name: Sophie Wang Mobile：+86 18681453433 Tel：+86 18681453433 Whatsapp：8613244706006 Email：sophie@meterbook.com Add：Jingying Plot,Baoan District,Shenzhen City,Guangdong Province,China We chat
Technical Data
Display
2.8” TFT (320×240)
IR resolution(Pixels)
256×192
Super resolution(Pixels)
✔ (512×384)
Spectral range
8~14µm
Pixel size
12µm
Frame rate
≤25Hz
Thermal sensitivity(NETD)
≤50mK
Focus
Focus Free
Field of view(FOV)
56°(H) × 42°(V)
Spatial resolution(IFOV)
3.75mrad
Temperature measurement range
-20℃~550℃
Accuracy
20℃~120℃, ±1.5℃ or ±1.5% whichever is greater
-10℃~20℃, 120℃~550℃, ±2℃ or ±2% whichever is greater
Functions
Color palette
White Hot, Black Hot, Red Hot, Ironbow, Lava, Rainbow, Rainbow HC
Image mode
Thermal, Visual image, T-Mix fusion, PIP
On screen analyzer
5 Points/3 Rectangles
HI/LO temperature alarm
LCD animation, LED flashlight, Buzzer
HI/LO temperature tracking
✔
Digital camera resolution
2MP
Video recording
✔
Wi-Fi/Wi-Fi live streaming
✔
LED lighting
✔
Analysis software
PC+APP
General Characteristics
Battery
5000mAh rechargeable Li-ion battery
Operating time
≥7 hours
USB
Type-C
Storage
Built-in 32GB
Image/video storage format
JPG/MP4
Protection
IP65 & 2m drop proof
Certificates
CE, FCC, RoHS
Languages
EN, FR, DE, IT, ES, SV, PL, CZ
