UTi740H Professional Enhanced Thermal Camera

UTi740H Professional Enhanced Thermal Camera

Product Item : UTi740H
Category： UNI-T
IR resolution (Pixels):384×288
Display:4.3″ IPS (800×480)
Field of view(FOV): 28°×21°
Thermal sensitivity(NETD):≤60mK
INQUIRY EMAIL

Industrial Enhanced Thermal Camera

UTi740H is a professional enhanced thermal camera that specially designed for industrial use with wide temperature range:-30℃~650℃. Its large 4.3 ” IPS display screen can clearly display 384×288 IR resolution and 5MP digital camera.The professional manual focus lens can flexibly adjust the focal length according to different objective’s distance and provide high quality image. UTi740H thermal camera is also with other features :such as WiFi capability ,Isotherm, on screen analyzer,etc. It is a perfect troubleshooting tools for many industrial applications.

Features :

4.3″ IPS display (800×480)
IR resolution:384×288
Temperature measurement range: -30℃ to 650℃
On screen analyzer :5 Points/1 Line/5 Rectangles/5 Circles
Digital camera resolution: 5MP
Focus: Manual focus
Digital zoom: 2x, 4x
Image modes: Thermal,Visual image,Fusion,PIP
Color palettes: 7(White hot, Black hot, Red hot, Ironbow, HC Rainbow, Rainbow, Lava)
Isotherm:2(Auto/Manual)
Wi-Fi connection through Mobile App
PC software: analysis and real-time image projection
5200mAh replaceable battery pack (Type-C rechargeable)
IP54
2m drop proof

Specifications

Technical Data
IR resolution (Pixels)	384×288
Display	4.3″ IPS (800×480)
Field of view(FOV)	28°×21°
Thermal sensitivity(NETD)	≤60mK
Spatial resolution(IFOV)	1.3mrad
Frame rate	≤25Hz
Spectral range	8~14µm
Focus	Manual
Temperature measurement range	-30℃ ~ 650℃
Accuracy	-20℃ ~ 650℃, ±2℃ or ±2% whichever is greater (ambient temperature at 25℃)
Emissivity	0.01~1.00 adjustable (0.95 default)
Functions
Color palettes	7 (White hot, Black hot, Red hot, Ironbow, Rainbow HC, Rainbow, Lava)
Image modes	Thermal,Visual image,Fusion,PIP
On screen analyzer	5 Points/1 Line/5 Rectangles/5 Circles
Digital camera resolution	5MP
Digital zoom	2x, 4x
Hi/Lo temperature alarm	Icon
Isotherm	Auto/Manual
Software analysis	PC+APP
Wi-Fi	√
General Characteristics
Battery	Detachable Li-ion battery pack(3.7V 5200mAh)
Battery operation time	About 5 hours (with Wi-Fi off)
USB	Type-C
IP rating	IP54
Drop proof	2m
Storage	32G Micro SD card
Image/Video storage format	BMP
Certificates	CE,UKCA,FCC,RoHS
