Intelligent Pro-grade Thermal Camera
UTi192M Intelligent Pro-grade Thermal Camera
- Product Item : UTi192M
- Category： UNI-T
- IR resolution (Pixels):192×144
- Display:4” LCD Touch (800×480)
- Field of view(FOV): 37.8°×28.8°
- Thermal sensitivity(NETD):≤50mk
UTi192M inherits the classic functions of high-end infrared thermal imagers, with simple appearance and ergonomic design. The touch-display screen menu navigation interface is convenient for users to operate easily. There are professional tips for each step, so that first-time users can also become experts! UTi192M/UTi384M is equipped with a high intensity light, so that you can easily take clear visible light and infrared contrast pictures, easier to find abnormalities. We also offer a wide range of high quality optional infrared lenses with higher temperature (1500℃ ) for different applications.
Features :
- 4” touch display screen (800×480 Pixels)
- IR resolution: 192×144
- Temperature measurement range: -20℃ to 650℃ , external lens up to 1500℃ / -4℉ to 1202 ℉, external lens up to 2732℉
- Interchangeable lens (Optional Telephoto lens / High Temp lens)
- Manual focus
- Auto alarm for high/low temperature
- Auto tracking for hot spot/cold spot
- On display screen analyzer: 5 Points/2 Lines/5 Rectangles/5 Circles
- Image capture
- Video recording
- Voice recording
- Bluetooth connection
- Digital camera resolution: 5MP
- Digital zoom: 1.1~4x (continuous zoom)
- Image modes: Thermal,Visual image,Fusion,PIP
- Color palettes: 8 (White hot, Fulgurite, Ironbow, Hot iron, Medical, Arctic, Rainbow 1, Rainbow 2)
- Isotherm : 2(Above, Below)
- LED flashlight
- Laser pointer
- Wi-Fi connection through Mobile APP
- PC software analysis and real-time image projection
- Replaceable battery pack
- IP54
Product Specifications of UTi192M
| Technical Data | |
| IR resolution (Pixels) | 192×144 |
| Display | 4” LCD Touch (800×480) |
| Field of view(FOV) | 37.8°×28.8° |
| Thermal sensitivity(NETD) | ≤50mk |
| Spatial resolution(IFOV) | 3.45mrad |
| Frame rate | ≤25Hz |
| Spectral range | 7.5~14µm |
| Focus | Manual |
| Temperature measurement range |
-20℃~650℃（standard lens） 650~1500℃ (optional lens) |
| Accuracy | ±2℃ or ±2% whichever is greater |
| Emissivity | 0.01~1.00 adjustable (0.95 default) |
| Functions | |
| Color palettes |
8 (White hot, Fulgurite, Ironbow, Hot iron, Medical, Arctic, Rainbow 1, Rainbow 2) |
| Image modes | Thermal,Visual image,Fusion,PIP |
| On screen analyzer | 5 Points/2 Lines/5 Rectangles/5 Circles |
| Digital camera resolution | 5MP |
| Digital zoom | 1.0~4x continuous |
| Hi/Lo temperature alarm | Icon,LED flashlight,Buzzer |
| Isotherm | Above, Below |
| Software analysis | PC |
| Video recording | √ |
| Voice recording | √ |
| Wi-Fi / Bluetooth | √ / √ |
| Laser pointer | √ |
| General Characteristics | |
| Battery | Detachable Li-ion battery (7.2V 2300mAh) |
| Battery operation time | ≥ 4 hours |
| USB | HDMI,Micro USB |
| IP rating | IP54 |
