UTi384M Intelligent Pro-grade Thermal Camera

UTi384M Intelligent Pro-grade Thermal Camera

Product Item : UTi384M
Category： UNI-T
IR resolution (Pixels):384×288
Display:4” LCD Touch (800×480)
Field of view(FOV): 28.4°×21.5°
Thermal sensitivity(NETD):≤45mK
INQUIRY EMAIL

Intelligent Pro-grade Thermal Camera

UTi384M inherits the classic functions of high-end infrared thermal imagers, with simple appearance and ergonomic design. The touch-display screen menu navigation interface is convenient for users to operate easily. There are professional tips for each step, so that first-time users can also become experts! UTi192M/UTi384M is equipped with a high intensity light, so that you can easily take clear visible light and infrared contrast pictures, easier to find abnormalities. We also offer a wide range of high quality optional infrared lenses with higher temperature (1500℃ ) for different applications.

Features :

4” Touch display screen (480×800 Pixels)
IR resolution: 384×288
Temperature measurement range: -20℃ to 650℃ , external lens up to 1500℃ / -4℉ to 1202 ℉, external lens up to 2732℉
Interchangeable lens (Optional Telephoto lens / High Temp lens)
Manual focus
Auto alarm for high/low temperature
Auto tracking for hot spot/cold spot
On display screen analyzer: 5 Points/2 Lines/5 Rectangles/5 Circles
Image capture
Video recording
Voice recording
Bluetooth connection
Digital camera resolution: 5MP
Digital zoom: 1.1~4x (continuous zoom)
Image modes: Thermal,Visual image,Fusion,PIP
Color palettes: 8 (White hot, Fulgurite, Ironbow, Hot iron, Medical, Arctic, Rainbow 1, Rainbow 2)
Isotherm : 2(Above, Below)
LED flashlight
Laser pointer
Wi-Fi connection through Mobile APP
PC software analysis and real-time image projection
Replaceable battery pack

IP54

Product Specifications of UTi384M

Technical Data
IR resolution (Pixels)	384×288
Display	4” LCD Touch (800×480)
Field of view(FOV)	28.4°×21.5°
Thermal sensitivity(NETD)	≤45mK
Spatial resolution(IFOV)	1.29mrad
Frame rate	≤25Hz
Spectral range	7.5~14µm
Focus	Manual
Temperature measurement range	-20℃~650℃（standard lens） 650~1500℃ (optional lens)
Accuracy	±2℃ or ±2% whichever is greater
Emissivity	0.01~1.00 adjustable (0.95 default)
Functions
Color palettes	8 (White hot, Fulgurite, Ironbow, Hot iron, Medical, Arctic, Rainbow 1, Rainbow 2)
Image modes	Thermal,Visual image,Fusion,PIP
On screen analyzer	5 Points/2 Lines/5 Rectangles/5 Circles
Digital camera resolution	5MP
Digital zoom	1.0~4x continuous
Hi/Lo temperature alarm	Icon,LED flashlight,Buzzer
Isotherm	Above, Below
Software analysis	PC
Video recording	√
Voice recording	√
Wi-Fi / Bluetooth	√
Bluetooth	√
Laser pointer	√
General Characteristics
Battery	Detachable Li-ion battery (7.2V 2300mAh)
Battery operation time	≥ 4 hours
USB	HDMI,Micro USB
